References

Siemensstadt Square District Heating Network Siemensstadt Square 3D View
  • Energy Transition
  • 4GDH/5GDH

  • Heat Pumps

Siemensstadt Square Berlin

In Berlin, the Siemensstadt Square project is being built as a smart campus of the future, which combines digitalization with energy efficiency and sustainability. Using our heatbeat Digital Twin, we simulate the heating and cooling supply of the district.

FunkSTA
  • District Heating and Cooling
  • Live Measurement Data

  • Energy Transition

FunkSTA

The research project 'FunkSTA: Operational optimization and expansion of renewable-fed district heating network for municipal utilities based on wireless communication technologies' is funded by the 7th Energy Research Program of the German Federal Government. Through the radio-based measurement data connection to our Digital Twin, we can calibrate and improve our simulation models.

Synergies of heating and cooling demands in the network Aerial view: The Shamrockpark in Herne
  • District Heating and Cooling
  • 4GDH/5GDH

  • Energy Transition

Shamrockpark Herne

An innovative, district heating and cooling network is being built in the Shamrockpark in Herne, funded by the BMWK. Our role is to map the buildings, the thermal network and the generators for heating and cooling in our heatbeat Digital Twin.

Figure: Ultra-low temperature district heating Figure: Building model ultra-low temperature district heating
  • District Heating and Cooling
  • Ultra-Low Temperature District Heating

  • Demo

Ultra-Low Temperature District Heating

What is ultra-low temperature district heating and what needs to be considered when developing concepts and planning ultra-low temperature district heating networks? With the help of our heatbeat Digital Twin, we demonstrate the most important points using a sample district heating network.

Brainergy Park Jülich under construction Brainergy Park Jülich: Vision of the future
  • District Heating and Cooling
  • Prosumer

  • Business Park

Brainergy Park Jülich

The Brainergy Park Jülich GmbH is developing a modern and innovative commercial district in which renewable energies and the coupling of energy sectors play a major role. For a coordinated energy system, heatbeat supports the planning by modelling and simulating the buildings and the heating networks.

part of map of the showcase langwasser part of map of the showcase langwasser
  • District Heating and Cooling
  • Demo

  • Variants

District Heating: Langwasser

We use an example network in a district of Nürnberg to demonstrate our methods and processes for the dynamic simulation of a district heating network. In this case study, we compare the simulated heat losses resulting from different levels of thermal insulation for the pipe network.

Shamrockpark Seestadt
  • District Heating and Cooling
  • 4GDH/5GDH

  • Energy Transition

TransUrban.NRW

The project TransUrban.NRW is a winner of the ideas competition 'Reallabore der Energiewende' of the Federal Ministry for Economic Affairs and Climate Action (BMWK). With our simulations we support the implementation of innovative 5th generation district heating networks at 4 locations in North Rhine-Westphalia.
